Center Finders Instrument Information
A metallic instrument containing a “V” base, a plunger and an angle readout. The part wished to have the center found for is inserted into the V and the plunger is depressed, giving an angle readout. True center is to be found, a mark should be made when the plunger is at 0 degrees.
Common Uses
- Quickly finding the center of square or round stock.
- Quickly and accurately determining angles.
Common Types
- Range
- Size
- Magnetic Base
Measurement Parameter
- Centering
Calibration Discipline
Calibration Equipment Used
- Angle Blocks
